Mini Loader ST 45

The ST 45 is a compact tracked loader manufactured by Wacker Neuson, designed to offer high operational capacity and an extended lift height, making it ideal for excavation and loading tasks.

Key Specifications:

  • Overall Length with Bucket: 3,660 mm
  • Overall Length without Bucket: 2,940 mm
  • Overall Width with Bucket: 2,030 mm
  • Overall Height: 2,108 mm
  • Wheelbase: 1,600 mm
  • Hinge Pin Height: 3,440 mm
  • Maximum Dump Height: 2,720 mm
  • Ground Clearance: 250 mm
  • Dump Angle: 30ยฐ

Operational Capacities:

  • Rated Operating Capacity at 50% Tipping Load: 2,041 kg
  • Rated Operating Capacity at 35% Tipping Load: 1,429 kg
  • Tipping Load: 4,082 kg

Engine:

  • Manufacturer: Kohler
  • Type: 4-cylinder diesel engine
  • Displacement: 3,359 cmยณ
  • Rated Power: 55 kW (74.3 hp) at 2,500 rpm
  • Battery Capacity: 950 Ah

Hydraulic System:

  • Standard Flow: 83 l/min
  • Maximum Flow: 120 l/min
  • Auxiliary Hydraulic Relief Pressure: 241 bar

Transmission and Speed:

  • Travel Speed in First Gear: 10.3 km/h
  • Travel Speed in Second Gear: 15.5 km/h

Additional Details:

  • Ground Pressure: 0.3 bar
  • Bucket Breakout Force: 30,875 N
  • Lifting Arm Breakout Force: 36,475 N
  • Maximum Traction Effort at 100% Effective Force: 49,280 N

This compact loader is ideal for various applications, providing excellent maneuverability and power for demanding tasks.
